OFNA Racing Ultra GTP MBX - Manual (Page 13)

3 x 15mm Screw
0 10 20 30 40 50
mm
15mm
30402
3 X 30mm
Tie Rod
30403
6mm
Ball Joint
30401
6mm
Stabilizer
Ball End
30401
6mm
Stabilizer
Ball End
30340
6mm
Stabilizer
Ball End
ASSEMBLY OF THE REAR UPPER ARM ROD
Assembly of the right and left hand side
are the same.
3 x 15mm
Screw
3 x 3mm
Set Screw
3 x 20mm
Cap Screw
3 X 25mm Cap Screw
3mm
Nylon Lock Nut
* Insert the stabilizer rod into arms
before assembly.
Sc
re
w
Ce
m
en
t
ASSEMBLY OF THE REAR STABILIZER ROD
3mm
Nylon Lock
Nut
3 x 25mm
Cap Screw
* Insert into rear hub.
3 x 20mm
Cap Screw
S
cr
ew
C em
en
t
S
cr
ew
C em
en
t
3mm
Flange Nut
3 x 15mm
Screw
M3
Nylon
Lock Nut
