Plastic parts used – OFNA Racing Jammin X2 Buggy User Manual
Page 8
PLASTIC PARTS USED
40541
RECEIVER BOX
40046
STONE GUARD
40540
REAR UPRIGHT & UPPER ARM
16015
WING
SYMBOLS USED THROUGHOUT THE INSTRUCTION MANUAL
Ensure
Free
Movement
Ensure Free
Movement
Apply
Grease
Apply Lubricant
Oil
Tighten
Tighten
Do Not
Over Tighten
Rotate
Direction
Rotate
Direction
Contact
Adhesive
Contact Adhesive
Ca Glue
Screw
Cement
BAG
1:1
Parts Bag Used
Degrease With
Motor Spray
Do Not
Over Tighten
Clockwise
Rotation
Counter-Clockwise
Rotation
True-To-Scale
Apply Oil
Apply Thread
Lock
1:1
40542
WING STAY
34026
SERVO FIXING
41052
SERVO SAVER
