ASSEMBLY OF THE REAR GEAR CASE

ASSEMBLY OF THE REAR SHOCK STAY

Step 1

94036
5x4mm
Set Screw

.....x1

94010
4x12mm
Hex Screw

.....x4

4x12mm

5x4mm

4x12mm

40562

Step 1

Step 2

40539

Step 2

41103

94003
3x10mm
Hex Screw

41009
3x28mm
Cap Screw

.....x2

ASSEMBLY OF THE REAR GEAR CASE

Step 2

4x40mm

40533

40576
3.0 Degree

4x16mm

40024
13x16x0.2mm
Shim

36053
8x16mm
Ball Bearing

.....x2

94011
4x16mm
Hex Screw

.....x2

.....x4

*Adjust the backlash with the shims.

Step 1

Apply
Grease

40024

40533

40024

36053

41032(10T)

36053

NO.4

BAG

94031
4x40mm
Flat Head Hex Screw

.....x2

Tighten

3x10mm

41020

41009

40542

41105

3x10mm

BAG

NO.4
NO.9

BAG

NO.3
NO.4

.....x3
