Mask the windows from
the inside with masking tape.

Paint the body with
polycarbonate spray paints.

Spray Paint

3x5mm

40539

Hole for fuel tank.

For the exhaust outlet
of the muffler.

8mm

Cut out for engine.

8mm

59

CUTTING OUT THE BODY AND PAINTING

60

ASSEMBLY OF THE REAR VIEW MIRROR

Cut out the body as shown.

Use a neutral detergent to
remove any dirt and oil.

61

MOUNTING THE NOSE PIECE

Step 1

3mm

3x8mm

Step 2

Cut Out

94041
3mm
Nylon Nut

.....x1

94001
3x5mm
Hex Screw

.....x2

94002
3x8mm
Hex Screw

.....x1

41110
Body(Option)
