Page 12

ASSEMBLY OF THE FRONT UPPER ARMS

Assemble both right and left sides

ASSEMBLY OF THE FRONT SUSPENSION ARMS

ASSEMBLY OF THE FRONT STABILIZER RODS

36850
7mm
Ball

.....x2

94008
3x25mm
Hex Screw

.....x2

3x8mm

40540

30403

30341

94035
3x8mm
Set Screw

.....x2

94006
3x18mm
Hex Screw

.....x2

36861
5x35mm
Turnbuckle

.....x2

Assemble for both right and left side

Approx. 7.5mm

1:1

36861

36850

40537

36690

Assemble both right and left sides

*Make two sets of rods for left
and right-hand sides.

3x25mm

3mm

40602(Short)

4mm

.....x2

94042
4mm
Nylon Nut

.....x2

94041
3mm
Nylon Nut

3x18mm

NO.2

BAG

NO.2

BAG

Tighten

BAG

NO.2
NO.4
