33 assembly of the front gear case onto chassis, 31 assembly of the center diff. mount, Assembl of the stone guard y 32 – OFNA Racing Jammin X2 Buggy User Manual

Page 19: No.3, No.3 no.10, No.3 no.5 no.8

ASSEMBLY OF THE FRONT GEAR CASE ONTO CHASSIS

3x10mm
Flat Head
Hex Screw

.....x2

94026
4x10mm
Flat Head
Hex Screw

.....x2

94021
4x16mm
Flat Head
Hex Screw

.....x4

3x10mm

4x16mm

4x10mm

*4x10mm screw is used
for servo saver tube.

ASSEMBLY OF THE CENTER DIFF. MOUNT

94032
3x30mm
Hex Screw

.....x4

3x3mm

Step 1

94033
3x3mm
Set Screw

.....x1

30171

Step 2

r w

c e

*Approx. 6mm

Cut Out

94002
3x8mm
Hex Screw

.....x1

3mm

94041
3mm
Nylon Nut

.....x2

3x30mm

3x8mm

3x30mm

40539

41051

*Cut out the shaded part.

Cut Out

ASSEMBL OF THE STONE GUARD

Assemble both right and left sides

94018
3x5mm
Flat Head
Hex Screw

.....x2

94019
3x10mm
Flat Head
Hex Screw

.....x6

3mm
Nut

.....x2

Step 2

3mm

40539

3x5mm

40046(Left)

*Drill two 3mm

holes for mounting.

3x10mm

3mm

41101

40046(Right)

Cut Out

40046(Right)

94041
3mm
Nylon Nut

.....x1

Step 1

NO.3

BAG

NO.3
NO.10

BAG

NO.3
NO.5

NO.8
