22 assembly of the wing stay, No.4 – OFNA Racing Jammin X2 Buggy User Manual

Page 16

background image

23

24

ASSEMBLY OF THE WING STAY

ASSEMBLY OF THE REAR WHEEL HUBS

Step 1

Step 2

94009
4x10mm
Hex Screw

.....x1

94036
5x4mm
Set Screw

.....x2

94011
4x16mm
Hex Screw

.....x4

94012
4x20mm
Hex Screw

.....x1

Step 1

40540

36870
4x10mm

Set Screw

.....x2

36055
2.5x16.8mm
Pin

.....x2

36053
8x16mm
Ball Bearing

.....x4

Step 2

Assemble both right and left sides

40603(Long)

*4x10mm set screw is
used to adjust ride-
height.

4x10mm
Set Screw

*Wheelbase
adjust washer

*Approx 2mm

22

ASSEMBLY OF THE WING STAY

94004
3x12mm
Hex Screw

.....x2

40542

40542

40542

40542

40542

3x12mm

3x16mm

3x16mm

94005
3x16mm
Hex Screw

.....x4

40542

3x12mm

Long Short

*Make two wing mounts
in the same position.

NO.4

BAG

High Position

Low Position

Big Angle

NO.4

BAG

4x16mm

4x10mm

4x20mm

41107

36053

36053

40571

36055

40526

40540

NO.4

BAG

5x4mm

40535

4x10mm

3mm

94041
3mm
Nylon Nut

.....x2

*Left side

40540

*The angle of wing mount can be adjusted.
