Page 14: No.3 no.4

ASSEMBLY OF THE STEERING TIE-ROD

ASSEMBLY OF THE SERVO SAVER ONTO GEAR BOX

Step 1

40039
3mm
Tappered Washer
(Alum.)

.....x2

40038
7mm Ball

.....x4

94021
3x15mm
Flat Head
Hex Screw

.....x2

40548
3mm
Nylon Nut
(Thin Type)

.....x2

Step2

Assemble both right and left sides

94021
3x15mm
Flat Head Hex Screw

.....x2

94009
4x10mm
Hex Screw

.....x2

3x15mm

40039

40548

*Make two steering rods for left and right hand-sides.

40038

36790(4x46mm)

36700

*Approx. 29mm

1:1

40039
3mm
Tappered Washer
(Alum.)

.....x2

ASSEMBLY OF THE SERVO SAVER

94041
3mm
Nylon Nut

3mm

.....x1

Step 1

Step 2

94009
4x10mm
Hex Screw

.....x2

94003
3x10mm
Hex Screw

.....x2

3x10mm

41107

4x10mm

40568

40074

40511

4x10mm

40074

40542

3x10mm

40074

40074
6x10mm
Ball Bearing

.....x4

Tighten

NO.3

BAG

4x10mm

40039

3x15mm

Sc ew

e t

Cem

3x15mm

40039

Front

40533
Front Plate pad

BAG

NO.2
NO.3

BAG

NO.3
NO.4
