56

57

ASSEMBLY OF THE WING

ASSEMBLY OF THE TIRES AND WHEELS

Step 1

Step 3

Step 2

T

IN

S

A

N

T

G

L

U

E

*Apply instant glue into the groove of the wheel.

3x12mm

40542

16015

86056-White
86057-Yellow
86058-Orange

*Drill two 7mm holes for mounting.

Body Reamer (Not included)

40542

3x12mm

3mm

3mm

94004
3x12mm
Hex Screw

.....x2

94041
3mm
Nylon Nut

.....x2

Step 1

58

ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE AND REAR HUB

Assemble both right and left sides

.....x4

40550
Wheel Nut

*To tighten the wheel nut, use M-35
(17mm) wheel nut tool.

Step 2

80003-Revolver Proline M2
1/8 Tires(Option)

81098-Yellow
81099-Red
1/8 Inner Foam Donut(Option)

40240

*Assembled Tire and Wheel

40550

BAG

NO.2
NO.4

NO.4

BAG

10239 Ca Glue
