No.1, No.2 – OFNA Racing Jammin X2 Buggy User Manual

Page 10

Dif

. O

ASSEMBLY OF THE CENTER DIFF.

ASSEMBLY OF THE FRONT GEAR CASE

ASSEMBLY OF THE FRONT ARMS HOLDER

Step 2

40024
13x16x0.2mm
Shim

36053
8x16mm
Ball Bearing

.....x2

94015
4x35mm
Hex Screw

.....x2

94005
4x16mm
Hex Screw

.....x2

40011

.....x4

5x4mm

40588(B)

*Caster angle can
be changed to
A or B

4x16mm

4x12mm

Steering
Characteristics

Steering response
becomes milder.

Steering response
becomes quicker.

Caster
(High/22 Degree)

Caster
(Low/20 Degree)

*NB. use only as matched set "A"
with"A"and "B" with "B".

94036
5x4mm
Set Screw

.....x1

94026
4x12mm
Flat Head Hex Screw

.....x2

94027
4x16mm
Flat Head Hex Screw

.....x2

Step 2

40589(B)

41103

*Fill the diff oil just level with the top
of the satellite gears.

80%

Step 1

.....x8

30776
4x10mm Washer

30774
4mm
Cross Pin

.....x2

94020
3x12mm
Flat Head
Hex Screw

.....x4

40513 30776

*Use the Diff. Oil #5000 for the center diff.
*Fill the Diff. case to approx. 80% with the Diff. Oil.

30774

Tighten

*Tighten the screws
equally.

*Tighten the diff screws in this order.

*Adjust the backlash with the shims.

Step 1

Apply
Grease

40024

40533

40024

36053

41032(10T)

36053

4x35mm

4x16mm

40533

40561

3x12mm

NO.1

BAG

NO.2

BAG

NO.2

BAG
