Page 22: No.7, No.3 no.8

ASSEMBLY OF THE CLUTCH

Step 2

*Place the clutch shoes with the clutch
springs over the 3 pins of the flywheel.
*Use a phillips screw driver or needle
nosed plier and bend the small end of
the clutch springs behind the pilot shaft
10098 then press down.

*Fit the flywheel using a pair of the
plier and cross wrench.

*Engine rotation direction.

38313

40573
(35mm)

10098

Step 1

10101

ASSEMBLY OF THE CLUTCH AND ENGINE MOUNT

5x9x0.3mm

34110

10403
(17T)

3x8mm

3x5mm

3x12mm

ASSEMBLY OF THE FUEL TANK ONTO CHASSIS

94003
3x10mm
Hex Screw

.....x2

3x10mm

40574

2.6x6mm

Step 2

Step 1

3x10mm

94019
3x10mm
Flat Head
Hex Screw

.....x2

3x5mm

Step 1

Step 2

.....x1

.....x4

10098
3x5mm
Cap Screw

94038
3x12mm
Cap Screw

.....x2

34110
5x10x4mm
Ball Bearing

.....x1

10098
5x9x0.3mm
Washer

10098
3x8mm
Washer

.....x4

10098
3x5mm
Spring Washer

Pressure Nipple

40539

3x5mm

10013

34110

NO.7

BAG

NO.7

BAG

3x12mm

BAG

NO.3
NO.8

*Use 10101 clutch shoe springs
(1.0 diameter) for .21 engine.

40543
