29

ASSEMBLY OF THE BRAKE PAD AND CENTER DIFF. MOUNT

Front

28

ASSEMBLY OF THE REAR STABILIZER

94033
3x3mm
Set Screw

.....x4

94002
3x8mm
Hex Screw

.....x4

3x3mm

3x3mm

40530
(2.5mm)

3x3mm

3x8mm

40533

NO.4

BAG

*Approx. 4mm

.....x2

30212
5x8mm
Flange Ball Bearing

94033
3x3mm
Set Screw

.....x1

94002
3x8mm
Flat Head Hex Screw

.....x4

94004
3x12mm
Hex Screw

.....x4

30171

30212

40614(Short)

40613(Long)

3x8mm

3x3mm

3x12mm

36660

41036

*Build two upper brake parts for front and rear.

41046

Step 1

Step 2

*Approx. 3.5mm

1:1

*Approx. 5mm

1:1

30212

3x8mm

NO.5

BAG

30

ASSEMBLY OF THE CENTER DIFF. INTO BRAKE DISK

41036

3x10mm

3x10mm

Step 1

41036

94019
3x10mm
Flat Head
Hex Screw

.....x2

41036

Step 2

41036

Step 3

40591

40591

NO.5

BAG
