24-0324

5

Part no. 24-0324 REV. A

ATTENTION: PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS

BEFORE ASSEMBLING, INSTALLING OR USING THIS PRODUCT.

INSTALLATION INSTRUCTIONS

INSTALLATION MANUAL

TRANSIT BULKHEAD — Model Numbers:

96301-3-01, 96302-3-01, 96311-3-01, 96312-3-01, 96321-3-01, 96322-3-01

STEP 7. FOR LOW ROOF TRANSITS: With the
Bulkhead against the

B-Pillar trim, use a marker or

pencil and mark the six Bulkhead side holes on the B
-pillar. Additionally mark and cut the B-pillar trim with
a 1" hole saw. Drill a pilot hole with an 1/8" drill bit.
Re-drill the hole with a 3/8” bit for the blind fasteners.

FOR MID AND HIGH ROOF TRANSITS: With the
Bulkhead against the

B-Pillar, use a marker or pencil

and mark the six Bulkhead side holes on the B-pillar.
Drill a pilot hole with an 1/8" drill bit. Re-drill the hole
with a 3/8” bit for the blind fasteners

Move the Bulkhead out of the way, and install six (6)
¼-20 blind fasteners. See INSTALLATION IN-
STRUCTIONS FOR BLIND FASTENERS on page 6.

STEP 8. FOR LOW ROOF TRANSITS
With the Bulkhead against the

B-Pillar, use a marker or pencil to mark
where the header panel intersects the roof
trim, and cut the roof trim with a knife.

STEP 9. Re-position the bulkhead and install using six (6) 1/4-20 x 1-1/4” hex head bolts and the
required six (6) 3/8” Mounting Spacers into the B-pillar blind fasteners. Mount header panel to
roof channel using (4) 1/4-14x3/4 self-tapping screws.
