Page 8

- 8 -
Konventioneller thermischer Strom bei gleichzeitiger Belastung mehrerer Kontakte/Conventional thermal
current while loading several contacts/Courant thermique conventionnel en cas de charge sur plusieurs
contacts (AC1, DC1)
Anzahl der Kontakte/number of contacts/nombre des contacts
3
2
1
I
th
(A) bei U
B
AC/at U
B
AC/pour U
B
AC
6,0
7,0
8,0
I
th
(A) bei U
B
DC/at U
B
DC/pour U
B
DC
7,0
8,0
8,0
Typ/
Type/
Type
PNOZ X3P C
PNOZ X3P
Merkmale/
Features/
Caractéristiques
24 V AC/DC
24 V AC/DC
Klemmen/
Terminals/
Borniers
Federkraftklemmen/spring-loaded terminals/
borniers à ressort
Schraubklemmen/screw terminals/borniers à vis
Bestell-Nr./
Order no./
Référence
787 310
777 310
Bestelldaten/Order reference/Caractéristiques
