PNOZ s10
Operating Manual PNOZ s10
21402-EN-08
9
Relay outputs 750110 751110
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Auxiliary contacts, AC15 at 230 V 230 V
Max. current 2,0 A 2,0 A
Auxiliary contacts, DC13 (6 cy-
cles/min) at
24 V 24 V
Max. current 2,0 A 2,0 A
Safety contacts, AC15 at 230 V 230 V
Max. current 6,0 A 6,0 A
Safety contacts, DC13 (6 cycles/
min) at
24 V 24 V
Max. current 7,5 A 7,5 A
Contact fuse protection, external
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Blow-out fuse, quick 16 A 16 A
Blow-out fuse, slow 10 A 10 A
Circuit breaker, 24V AC/DC,
characteristic B/C
10 A 10 A
Contact fuse protection, external
auxiliary contacts
Blow-out fuse, quick 4 A 4 A
Blow-out fuse, slow 2 A 2 A
Circuit breaker, 24 V AC/DC,
characteristic B/C
2 A 2 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Conventional thermal current
while loading several contacts
750110 751110
Ith per contact at UB DC
Conv. therm. current with 1 con-
tact
12,00 A 12,00 A
Conv. therm. current with 2 con-
tacts
11,00 A 11,00 A
Conv. therm. current with 3 con-
tacts
9,00 A 9,00 A
Conv. therm. current with 4 con-
tacts
8,00 A 8,00 A
Times 750110 751110
Switch-on delay
With automatic reset after power
on typ.
30 ms 30 ms
With automatic reset after power
on max.
50 ms 50 ms
Delay-on de-energisation
With E-STOP typ. 20 ms 20 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 20 ms 20 ms
With power failure max. 30 ms 30 ms
