PNOZ s10
Operating Manual PNOZ s10
21402-EN-08
8
Technical details
General 750110 751110
Approvals CCC, CE, GOST, KOSHA, TÜV,
cULus Listed
CCC, CE, GOST, KOSHA, TÜV,
cULus Listed
Electrical data 750110 751110
Supply voltage
Voltage 24 V 24 V
Type DC DC
Voltage tolerance -20 %/+20 % -20 %/+20 %
Output of external power supply
(DC)
3,0 W 3,0 W
Residual ripple DC 20 % 20 %
Continuous duty 100 % 100 %
Max. overall cable resistance Rl-
max
Single-channel at UB DC 30 Ohm 30 Ohm
Voltage at
Input circuit DC 24,0 V 24,0 V
Current at
Input circuit DC 95,0 mA 95,0 mA
Number of output contacts
Instantaneous safety contacts
(N/O)
4 4
Auxiliary contacts (N/C) 1 1
Inputs 750110 751110
Number 1 1
Relay outputs 750110 751110
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Auxiliary contacts, AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 2,0 A 2,0 A
Max. power 500 VA 500 VA
Auxiliary contacts, DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 2,0 A 2,0 A
Max. power 50 W 50 W
Safety contacts, AC1 at 240 V 240 V
Max. current 12,0 A 12,0 A
Min. current 0,01 A 0,01 A
Max. power 3000 VA 3000 VA
Safety contacts, DC1 at 24 V 24 V
Max. current 12,0 A 12,0 A
Min. current 0,01 A 0,01 A
Max. power 300 W 300 W
