DIP switches
These switches define the printer's settings. For information about
changing the factory default settings, see Chapter 8, Customizing the
Printer.
Assembling the Printer
Now that you are familiar with the components of your printer, you are
ready to set up the printer and connect to your computer. The first step
is to install the ink cartridge.
Installing the Ink Cartridge
The ink cartridge you use with the printer is BC-01. Each ink
cartridge contains enough ink to print about 400 to 500 pages
(700,000 characters) in high quality mode (HQ) mode, and 800
to 1000 pages (1,400,000 characters) in economy mode. The
actual amount varies according to the print density of the page.
If you print a lot of graphics, you may need to change the
cartridge more often.
CAUTION: Canon makes two ink cartridges that would fit the
printer; the BC-01 is designed specifically for the Bubble Jet
Printer BJ-10sx. Therefore, use only the BC-01 cartridge with
this printer.
