APPENDIX
Bottom ■ USB Cradle
Front
Back
bs Battery/Memory Card Slots (pages 36, 47)
bt Cradle Contact (page 38)
ck Tripod Hole
Use this hole when attaching to a tripod.
cl Speaker (page 140)
bt ck cl bs
1 Camera Contact (page 38)
2 USB Lamp
(pages 213, 227, 251)
3 [USB] Button
(pages 200, 213, 227)
4 [PHOTO] Button
(pages 146, 147)
5 [CHARGE] Lamp
(pages 38, 251)
6 [AV OUT] (AV output port)
(page 147)
7 [ ] (USB) Connector
(pages 198, 212, 226)
8 [DC IN 5.3V] (External Power)
Terminal (page 37)
5
1
2
3
4
6
8
7
