Sideburner conversion (con’t.) – Char-Broil 4539937 User Manual
Page 21
Sideburner
Sideburner
Drip Pan
17
- Reinstall the burner as Shown in illustration A.
- Make sure the burner tube is properly aligned with the sideburner valve as
- Reinstall the wingnut to the burner stud. Attach the ignitor wire to the electrode as
Shown in illustration B.
Shown in illustration C.
6
A
Electrode
Sideburner
Ignitor Wire
Wing Nut
C
Sideburner Conversion (Con’t.)
6
- Place sideburner cooking grate onto sideburner shelf, aligning grate legs with holes in shelf as shown below.
6
18
Burner tube
Va
lve
B
Proper Alignment
Sideburner Grate
21
