8 80016835 Ver A Welch Allyn
Reset the Micropaq monitor radio
It may be necessary to return the radio card to its default settings if:
• A network security setting was enabled that is not supported by the network
infrastructure.
• The network name was changed incorrectly.
• The default password was changed and forgotten.
The Reset Radio menu may be entered from either the Network Status screen or the
Network Monitor screen.
The Reset Radio menu can only be entered under the following conditions:
• The monitor is equipped with a working 5 GHz radio card
• There is no patient connection active
• There is no Acuity connection active
• The radio card has finished its initialization and is ready to accept the Reset
Defaults command
• No Radio Card Shutdown has been initiated
• No Firmware Update Operation has been initiated
• No other Reset Radio request has been accepted (only one active request
allowed)
To reset the monitor radio
1. Press to access the Main menu, and then repeatedly press until SYSTEM
INFORMATION MENU is highlighted.
2. Press to display the SYSTEM INFORMATION MENU screen.
3. Press repeatedly until NETWORK STATUS MENU is highlighted.
4. Press to display the NETWORK STATUS MENU screen.
5. While the Network Status screen is displayed, press and hold . While holding ,
press . The Reset Radio menu screen appears.
6. To reset the radio card to its default settings use to select YES and press .
7. To exit the Reset Radio menu without resetting the radio card use to select NO
and press .
If YES was selected in step 6, the monitor waits for the radio card to complete its reset
operation and then the monitor powers itself off. Remove and reinsert the battery to
restart the unit.
If NO was selected, the monitor returns to the Network Status screen.
