Radio configuration guide 80016835 Ver A 11
2. Press the unlabeled menu keys in the exact following sequence: 4 > 1 > 3 (see the
above graphic). The sequence must be completed within 5 seconds of pressing the
first button.
If the button sequence is entered correctly, the Reset Radio Card menu appears.
3. Press YES to reset the radio to its factory default settings. Press NO to exit the
menu.
Radio configuration tool user interface
The radio configuration tool user interface is for users who want to configure Propaq CS
monitors or do not want to configure their monitors through the monitor user interface.
The tool allows for additional network setting customization that can not be configured
through the monitor user interface.
This interface is largely self-explanatory to anyone qualified to use it. This procedure
covers only the fields that might raise questions.
To configure a monitor through the radio configuration tool user interface
1. Navigate to the Service menu of your monitor as described.
2. Read the IP address from the monitor.
3. Enter the monitor IP address as a URL in your Web browser. A logon screen appears.
Note If the Reset Radio menu is accessed immediately after the monitor is powered
on, the YES button is blank and will not function until the radio card has been
initialized.
RESET RADIO CARD
T1
° C
NO
RESET RADIO CARD SETTINGS TO
DEFAULT
MONITOR WILL RESTART
ARE YOU SURE?
YES
37.0
Note Accessing the radio configuration tool requires your monitor to be connected to a
network.
