System description – Welch Allyn Stryker Light Source For Q2002-00, Q2002-02, Q2002-04, Q2002-06 - User Manual User Manual
Page 8
1-4
System Description
The Stryker Light Source is used to supply high quality, white light for
video and optical illumination systems. It accepts standard ACMI
connectors.
Power
Switch
Fiber Optic
Bundle Port
Light
Control
Knob
Fan Grill
Fuse
Drawer
AC
Power
Input
FRONT
BACK
Mounting Post
Mounting Bracket
BOTTOM
