System Setup and Operation (continued)
Continue with steps 5 & 6 if you are using the BCAM 1000 C-Mount
Video Camera
5. Connect the BCAM power/video cable from the camera to the VIDEO IN
CAMERA port on the light source front panel.
6. Connect a video cable from either the S-Video or composite video-
out port on the light source front panel to a monitor or video recording
device.
BCAM 1000
BCAM 1000 C-Mount Video Camera
Monitor or Video Recording Device
ELSV-60 Hi-Lux Light Source
8 ELSV-60 Light Source
