System Setup and Operation
CAUTION:
1. Verify that the supply voltage is within the 100-240VAC range specified
for this product.
2. To prevent temporary blinding, insert light guide into socket before turn-
ing power ON.
3. The light guide tip and light source socket will be hot when light guide is
removed.
CONTROLS & PORTS
ON/OFF Switch
A two position rocker switch is used to turn the unit on or off. Depressing the
side marked with a ( I ) turns the unit on, while depressing the side marked
with an (
 ) turns it off.
Light Intensity Control Knob
This knob on the front panel rotates to adjust the amount of light transferred
into the light guide. Rotating the ring clockwise will increase the amount of
light in the image and rotating the ring counter clockwise will decrease the
amount of light. This manual control is helpful when trying to better illuminate
one part of the image or when trying to reduce blooming.
Light Exit/Light Guide Socket
Socket will accept Olympus style adapter.
Video-In Camera Port
When using a borescope with the BCAM C-Mount Camera, the BCAM power/
video cable connects to the light source here. It carries power from the light
source to the camera, and brings the camera video back to the light source
video channel. It can not be used with cameras other than the BCAM.
Video-Out Ports
When using a borescope with the BCAM C-Mount Camera, the camera video
is accessed at either of these ports. Connect either an S-Video or composite
BNC cable from the appropriate output port to a monitor for display, or other
peripheral device for recording.
6 ELSV-60 Light Source
