HS-2010MED Index
I
Numerics
4 Channel Servo Board 4–14
A
ACP-8000P System 1–10
Applications 1–10
AutoCam Philosophy 1–12
B
Balance, Checking 4–4
Balance, Horizontal 3–9
Balance, Vertical 3–9
Balancing The Payload 3–9
Brakes, Pan and Tilt 2–10
Brushless Motors 4–17
C
Calibration
ENG Lens 4–10
Focus 4–7, 4–8, 4–11
Native Lens Board 4–6
Zoom 4–6, 4–7, 4–11
Checking Balance 4–4
Controls, Location 2–2
Convert, Manual To Robotic Mode 2–12
Convert, Robotic To Manual Mode 2–8
Critical Data For HS-2010MH iii
Customer Responsibility 1–3
D
Data Bus, Theory Of Operation 4–14
Drag, Pan and Tilt 2–8
E
Electrical Installation 3–10
Electronics Repair 4–12
ENG Lens Calibration 4–10
F
Focus Calibration 4–7, 4–8, 4–11
Focus Driver Board 4–15
H
HCP-8000P System 1–11
Head, Mounting 3–4
Horizontal Balance 3–9
HS-2010MH
Key Features 1–8
Specifications 1–9
HS-2010MH, Critical Data iii
I
Installation, Electrical 3–10
Installation, Tools Needed 3–2
L
Lens Calibration 4–10
Location Of Controls 2–2
Locking The Tilt Cradle 2–6
M
Maintenance
Checking Balance 4–4
Overall Operation 4–4
Maintenance, Routine 4–4
Manual Mode 2–8
Manual Mode, Convert From Robotic 2–8
Manual Mode, Convert To Robotic 2–12
Manual Outline 1–6
Motor Drive Amplifiers 4–17
Motors, Brushless 4–17
Mounting The Head 3–4
Mounting The Payload 3–6
MultiController II System 1–11
