HS-2010MED Operation
2-2 User Manual
Introduction
This chapter covers operation of the pan and tilt head and is limited to the
switches, controls and other features on the heads themselves.
Operating procedures for controlling the head remotely are described in the
User Manual for the specific controller in your installation.
Location Of Controls
Refer to the following illustrations to locate the various controls. Use of the con-
trols is described in the next section.
Tilt Drag
Adjustment
Manual/Robotic
Switch
Pan Brake Lever
