Electrical installation, Electrical installation –10 – Vinten Radamec HS-2010MED Pan & Tilt Head User Manual
Page 46
HS-2010MED
Installation
3-10
User Manual
Electrical Installation
A typical AutoCam system configuration is shown below. Installation of the
controller, pedestals and other equipment is described in the User manuals for
those products.
Note the pedestals may be robotic (as shown) or manual.
Electrical connections for the HS-2010MED head are described in the next sec-
tion.
Video Switcher
Video Switcher
ACP-8000P
ACP-8000P
