HS-2010MED Safety & Introduction
1-8 User Manual
HS-2010MED Pan/Tilt Head
Key Features
• 200 lb. (90 kg) payload
• 90 arc second accuracy
• Manual/Remote head with easy change-over
• Electronic drag system
• Brushless servo technology
• Robust construction
The HS-2010MED is a servo pan & tilt head designed to support any combina-
tion of camera, lens, viewfinder and teleprompter up to a maximum payload of
200 lbs. (90 kg) This makes it the ideal choice for broadcast studios and video
production facilities. The HS-2010MED is designed as a dual purpose head that
can be operated in servo control mode for remote operation or in full manual
mode.
In manual mode, the electronic drag system delivers the smooth and continu-
ously variable drag over a wide range.
The HS-2010MED is a post head which provides perfect balance about the hori-
zontal and vertical centers of gravity. Excellent performance is achieved in both
remote and manual modes.
Features of the HS-2010MED include: 20 bit servo precision for 90 arc second
accuracy (0.25” at 50 feet); non-lubricated, self-aligning gear train and rugged
