Eng lens calibration, Getting started, Eng lens calibration –10 – Vinten Radamec HS-2010MED Pan & Tilt Head User Manual
Page 60
HS-2010MED
Maintenance And Repair
4-10
User Manual
ENG Lens Calibration
For systems that use ENG style lenses, the lens servo in the head must be cali-
brated to ensure that the controller is capable of generating full end to end
motion of the lens elements for zoom and focus.
Getting Started
Use a hex key to remove the access cover in the housing.
Locate and identify the calibration pots and switches.
Access Cover
Zoom Wide
Zoom Tight
Focus Near
Focus Far
Focus Range
Zoom Range
