6
3 General Operation
The layout of the M2000 indicator is shown below.
2000
3.1 Keypad Functions Keys
The M2000 has several function keys, all of which are selected via the front
panel. The function key operations are discussed below. All the keys have
audio feedback when a key is pressed. The sound volume can be set in
calibration mode.
A description of the important keys and buttons are as follows:
Indicator [ZERO] Key
Indicator [TARE] Key
Indicator [PRINT/SELECT] Key
3.1.1 On/Off Key
This is the ON/OFF button for the indicator. Pressing the switch once turns
on the indicator. To turn off the indicator press the switch for 1 second. It is
important to note that there is a power bypass switch option flag that can be
set in calibration (parameter 10). If power bypass is enabled the indicator will
always be on and cannot be turned off via the ON/OFF button. This option
