6.4. DI- 28 Specification List
6.4.1. DI - 28 W & M Specs.
W & M SPECS. PRESS AND HOLD REZERO THEN PRESS (D - T - D)
Spc. No. BIT 3 BIT 2 BIT 1 BIT 0
Spec. 00 Not Used
Spec. 01 Comma or
Dec. Pt. Not Used Decimal Point Position
0 =comma,
1= dec.pt. 00 = no dec.pos.
01 = one dec.pos. 10 = two dec.pos.
11 = three dec.pos.
Spec. 2 Not Used
Spec. 3 Change
Weight Units
0 = no,
1 = yes
Scale Type
0 = kg ,
1 = lb
Internal Count
When Span SW
off
0 = no, 1 = yes
Not Used
Spec.
04-09 Not Used
Spec. 20 Tare
Accumulate
0 = no,1 = yes Not Used Digital Tare
0 = no, 1 = yes Tare Limit
0= 50%, 1 = 100%
Spec. 21 One Touch
Tare Clear
0 = no,1 = yes Rezero In
Tare
0 = no,
1 = yes Not Used Not Used
Spec.
22-23 Not Used
Spec. 24 load cell sensitivity (mv/V)
0000 = 4.00mV/V
0001 = 3.75mV/V
0010 = 3.50mV/V
0011 = 3.25mV/V 0100 = 3.00mV/V
0101 = 2.75mV/V
0110 = 2.50mV/V
0111 = 2.25mV/V 1000 = 2.00mV/V
1001 = 1.75mV/V
1010 = 1.50mV/V
1011 = 1.25mV/V 1100 = 1.00mV/V
1101 = 0.80mV/V
1110 = 0.70mV/V
1111 = 0.60mV/V
Spec. 25 Not Used Not Used Ignore Span
Switch
0 = no, 1 = yes
Recall Zero
0 = no, 1 = yes
Spec.
26-27 Not Used
Spec. 28 Not Used Minus Weight
0 = 9 ext.
increments,
1 = No Limit
Zero Reset Range
0 = ± 10% , 1 =±
100%
Re-Zero Range
0 =
± 2 % , 1 =
± 100%
Spec. 29 Not Used
[16]
6.4. DI - 28 Specification List (Continued)
6.4.2. DI - 28 Operational Specs.
OPERATIONAL SPECS. PRESS AND HOLD REZERO THEN PRESS (D - D - D)
Spc. No. BIT 3 BIT 2 BIT 1 BIT 0
Spec. 50 Sleep Timer
0000 = None
0001 = 1 Min.
0010 = 2 Min.
0011 = 3 Min. 0100 = 4 Min.
0101 = 5 Min.
0110 = 6 Min.
0111 = 7 Min. 1000 = 8 Min.
1001 = 9 Min.
1010 = 10 Min.
1011 = 11 Min. 1100 = 12 Min.
1101 = 13 Min.
1110 = 14 Min.
1111 = 15 Min.
Spec. 51 Not Used Power Save
0 = no, 1 =
yes Motion Detection
0 = strong ,
1 = weak Animal Mode
0 = no, 1 = yes
Spec. 52 Handshaking
for RS-232
0 = no, 1 = yes
Send STX
Before Text
0 = no,1 = yes
Set Point Output
0 = active low,
1= active high
Set Point
0 = disable,
1 = enable
Spec. 53 RS-232 Stable
Flag
0 = without
flag
1 = with stable
flag
RS-232 Data
Format
0 = without
header
1 = with
header
Non-Stable
Output
0 = no, 1 = yes
Send Header As
Text
0 = no, 1 = yes
Spec. 54 RS - 232
Output
0 = Disable
1 = Enable
0 0 0=1200 bps
0 1 1=9600 bps Baud Rate
0 0 1 = 2400 bps
1 0 0 = 19200 bps
0 1 0 = 4800 bps
Spec. 55 Parity
0 0 = no parity 0 1 = odd
1 0 = even
Stop Bit
0 = 1 bit
1 = 2 bits Data Length
0 = 7 bits
1 = 8 bits
Spec.
56-58 Not Used
Spec. 59 Remote
Trigger
0 = Disable
1 = Enable
Communicatio
n Mode
0 = stream
1 = manual
RS-232 Time Out
0 0 = 1 sec.
0 1 = 3 sec. 1 0 = 5 sec.
1 1 = 10 sec.
[17]
