Options (continued)
7.4.4. RS-232 Communication Protocols
7.4.4.1. Text Format
STX* Stable flag CR *Header Net weight CR *Header Tare
weight
CR LF
1 1 1 1 7 1 1 7 1 1
* Options set in Spec.
Stable Flag
* Header
(Send as code or text depend on SPEC 53 bit 0)
Stable flag Data Header As Code As Text
Stable SOH (01H) Net weight 0 (30H) NET WEIGHT :
Unstable NUL (00H) Tare 4 (34H) TARE WEIGHT :
Text
Text Data
0 ~ 9 30H ~ 39H
. 2EH
, 2CH
- 2DH
Example: Net Weight = - 1.20 lb. Tare Weight = 0.45lb.
(a) Header Send As Code
S
T
X S
O
H C
R 0 - 0 1 . 2 3 0 C
R
4 0 0 0 . 4 5 0 C
R
L
F
[24]
5. Operation Procedure
5.1 Power On
PROCEDURE KEY OPERATION DISPLAY REMARKS
Connect DI-28SS to power supply.
Ver0.01 Show
Software
Version
1. Make sure nothing is on the
platform, and press [ON/OFF]
key.
000000 Segment
check starts.
888888
0.000 Ready for
weighing
5.2 Tare Subtraction
5.2a One touch tare
PROCEDURE KEY OPERATION DISPLAY INDICATOR
0 NET
Stand-by status 0.000 ♦
1. Place tare weight on the
platform. e.g. 0.010 kg 0.010
2. Press [TARE] key.
0
0.000 ♦
3. Remove the tare weight. -0.010 ♦ ♦
Note 1) To clear the tare weight, remove tare from the load
receptor then, press[TARE] key.
5.2b Digital tare entry (When the tare weight is known)
PROCEDURE KEY OPERATION DISPLAY INDICATOR
0 NET
Stand-by status 0.000 ♦
1. Move cursor to the left two
digits.
, t00.0”0”0
2. Set tare value by increasing
the value.
, t00.0”2”0
3. Enter the tare value. -0.020 ♦ ♦
Note 1) To clear the tare weight, press [TARE] key.
Note 2) “0” and “2” means that the cursor is blinking.
[9]
