Rice Lake Digi DI-28SS Bench Scale - Manual (Page 10)

4.3. Control Panels
4.3.1. Keys
Key Name Functions
ON/OFF Turn power on or off.
REZERO Reset the weight to zero.
TARE Enter or clear tare value.
DIGIT SELECT Select the digits to set tare or setpoint value.
INCREASE Increase the value of tare or setpoint weight
on selected digit when setting data. Manual
transmit key for RS-232 output.
4.3.2. Lamps
Indicators
Name Functions
BATTERY
LAMP
On when battery becomes too weak and
needs to be replaced/ recharged.
O ZERO LAMP On when weight is stable at zero point.
NET NET LAMP On when tare is subtracted.
g GRAM LAMP On when grams are used as weighing unit.
lb/kg LB/KG LAMP On when pounds are used as weighing unit.
[8]
(a) Header Send As Text
S
T
X S
O
H C
R N
E
T
W
E
I
G
H
T
: - 0 1 . 2 3 0 C
R
T
A
R
E
W
E
I
G
H
T
: 0 0 0 . 4 5 0 C
R
L
F
NOTE:
✍ Net Weight and Tare Weight excluding a sign are
transmitted shifting to the right.
✍ When it is minus data (0x2D) or plus data (0x30), net and tare
weight data are transmitted setting 2DH or 30H into the left most
byte of each 7 byte data block.
✍ In case of over weight, the data will transmitted as follows:
0 OV 00000 CR 4??????? CR LF
✍ Decimal points are transmitted as[ , ] comma 0x2C or [ . ]
Period 0x2E (See Spec 01 bit 3)
[25]
O
T
