Hygienic Weighing Module Contego® Installation Manual
EN-8 Sartorius
3.2 Weighing Module
3.2.1 Types
3.2.1.1 Weighing Module Incl. Load Cell
For nominal load E
max
Error class Type*
100 kg D1 A, Ex A, B, Ex B
200 kg D1, C3 A, Ex A, B, Ex B
300 kg D1, C3 A, Ex A, B, Ex B
500 kg D1, C3 A, Ex A, B, Ex B
1 t D1, C3 A, Ex A, B, Ex B
2 t D1, C3 A, Ex A, B, Ex B
* A = cable outlet on side
B = cable outlet on top
Ex = for installation in the explosion-hazarded area
3.2.1.2 Weighing Module without Load Cell (Service)
PR 6041/60S Mounting kit with cable outlet on side
PR 6041/70S Mounting kit with cable outlet on top
3.2.2 Technical Specifications
Permissible horizontal force 7 kN
Permissible vertical load without load cell 1.5 t
Permissible lift-off force 8 kN
Permissible force for jack-up 15 kN
Permissible temperature range -40 °C to +95 °C
Protection classes
Dust and water
IP69K:
Protection against dust
as per DIN EN 60529 09/2000 Paragraph 13.4
Protection against water (high-pressure cleaning)
as per DIN 40050 Part 9
Explosion Suitable for sub-groups IIA, IIB, and III for explosive
atmospheres. Please ask regarding IIC compliance.
Material
Bellow Silicone (FDA-compliant)
Mounting kit 1.4404 (AISI 316L)
Weight of
cpl. weighing module
net approx. 11 kg
gross approx. 12 kg
