Appendix 29
7.0 Appendix
7.1 Error Messages
Table 7-1. 120 Error Messages
Error Message Description Solution
_ _ _ _ _ _
(bottom LED segments lit)
Display overflow (negative) Negative weight value too large to be
displayed (< –99999)
_ _ _ _ _ _
(middle LED segments lit)
Overload Weight value exceeds scale capacity
_ _ _ _ _ _
(top LED segments lit )
Display overflow (positive) Positive weight value too large to be
displayed (> 999999)
7.2 Continuous Output (Stream) Format
Figure 7-1 shows the continuous output format sent to the 120 EDP or printer port when the STREAM parameter
(SERIAL menu) is set to either EDP or PRN.
ASCII 02
(decimal)
Polarity:
= Positive
<–> = Negative
Weight data: 7 digits, right-justified, with
decimal point, leading zero suppression.
Error =
- - - - - -
L = pounds
K = kilogram
T = ton
G = grams
O = ounces
= none
G = Gross
N = Net
Status:
= valid
I = Invalid
M = In motion
or
ASCII 13, 10
(decimal)
ACE> < / >
ASCII 32
(decimal) ASCII 32
(decimal) ASCII 47
(decimal)
Time: 8 digits, hh:mm:ss
hh: 00–24
mm: 00–59
ss: 00–59 Date: 2 digits, dd
dd: 01–31 Raw count: 8 digits
00000000–16777216
Figure 7-1. Continuous Output Data Format
