16 120 Installation Manual
STMDLY 250MS
500MS
1SEC
2SEC
4SEC
8SEC
15SEC
NONE Stream delay. Specifies the delay, seconds (SEC) or milliseconds (MS), inserted between stream
frames.
PRNDES EDP
PRN Print destination. Selects the port for data transmission when the PRINT key is pressed or the
KPRINT EDP command is sent.
PROTCT ENABLE
DISABL EDP port protection. Select ENABLE to secure the EDP port from configuration changes.
Level 3 Submenus EDP Port
BAUD 9600
19200
38400
1200
2400
4800 Baud rate. Selects the transmission speed for the EDP port.
BITS 8NONE
7ODD
7EVEN
7SPACE Selects number of data bits and parity of data transmitted from the EDP port.
TERM CR/LF
CR Termination character. Selects termination character for data sent from the EDP port.
ECHO ON
OFF Echo. Specify whether serial commands sent to the indicator are echoed.
Level 3 Submenus Printer Port
BAUD 9600
1200
2400
4800 Baud rate. Selects the transmission speed for the printer port.
BITS 8NONE
7ODD
7EVEN
7SPACE Selects number of data bits and parity of data transmitted from the printer port.
TERM CR/LF
CR Termination character. Selects termination character for data sent from the printer port.
SERIAL Menu
Parameter Choices Description
Table 3-5. Serial Menu Parameters (Continued)
