1s pack – ProgressiveRC 8 PowerLab User Manual

Page 66

  • Text mode
  • Original mode
background image

FMA Cellpro Connector/FMA Wiring Mode

Pin 1

Red

Black

Pack positive

Pack negative

1s Pack

Pack positive

(red), 3.7V*

Pack negative

(blk), 0V

Cell 1

* Nominal voltage with

respect to pack negative


FMA Cellpro Connector/FMA Wiring Mode












66
