Node Wiring =: When set to FMA Wiring, PowerLab looks for FMA/Cellpro wiring
convention on the balance port. When set to XH/EH Wiring, PowerLab looks for the
JST XH/EH wiring convention on the balance port. See
FMA Wiring mode vs. XH/EH
Wiring mode later in this user guide for more details.
Enable Quick Start: When checked, you can skip over a preset’s questions
regarding available modes of operation—just press and hold ENTER—when
preparing to charge a pack at the PowerLab 8.
Suppress Use Bananas Question: When checked, the charge sequence does not
ask whether you are charging using the banana cable.
Choose Power Source at Startup: When checked, you must always specify the
power source immediately after applying power to PowerLab 8.
Note: If this option is checked, PowerLab 8 assumes you are charging using
the banana cable. Attempting to charge using only balance wires will result in
a Safety Code.
Tip: If you always use the same power source, specify the power source in
the Supply tab , then uncheck the Choose Power Source at Startup option.
This will save you a step each time you power up the PowerLab 8.
Save and load options
To save a set of options on your computer: Click the Save to File... button. Select a
Folder, enter a name, then click the Save button.
To load a set of options from your computer:
1. Click the Load from File... button.
2. Locate and select the options file, then click the Open button.
3. Click
the Update button to download the options to PowerLab 8.
