11
Charging a pack or packs
1. Before charging, pack(s) must be properly connected to the charger. See “Connecting packs
to the charger,” earlier in this manual, for details.
2. Press the Start/Stop button for one second to enter Charging Mode.
3. You will see the following screens in sequence:
Checking Pack(s)
CHARGING Press
MODE for info.
4. While in Charge Mode, you can take the following actions:

To view pack and operating data: Press the Mode button repeatedly to cycle through the
following screens. (These examples assume two packs are being charged; if one pack is
being charged, only the top line may appear in some screens.)
C 0.5A 00:00:59
Supply=13.8V/ 1A
[preset name]
[chem] Set @ [charge current]
Ch1 [chemistry] [charge process]
Ch2 [chemistry] [charge process]
Ch1 Fuel = 47%
Ch2 Fuel = 55%
Ch1 Pack = 11.754V
Ch2 Pack = 11.821V
Ch1 42mAh In
Ch2 40mAh In
1:3.835V 2:3.955V
3=3.959V 4=3.873V
1:23.3mΩ 2:17.1
3=12.1mΩ 4=25.7
*Cells are numbered from 1 through n, where 1 is the first cell in the pack connected to Ch1, and n is the
last cell in the pack (if only one pack is being charged) or the last cell in the pack connected to Ch2 (if two
packs are being charged).
†For the charger to calculate internal resistances, a) pack discharge wires must be connected during
charging and b) pack must be at less than 80% fuel level. Internal resistances will be available for display
after about 12 minutes of charging, and will be periodically updated after that.
Selected preset.
Preset’s charging settings.
Chemistry and charge process
(Fast Charging, Balance Charg-
ing, etc.) in effect for each
channel.
Results of unique FMA algorithm
that determines pack “fuel level.”
Data is also used to calculate cor-
rect C rate during 1/2/3C charging.
Total pack voltage(s).
mAh put back into pack(s) dur-
ing charging.
Individual cell voltages.* “:” indicates
Ch1, “=” indicates Ch2. Similar screens
may appear, depending on the number
of cells being charged.
Individual cell internal resistances in
milliohms.*† “:” indicates Ch1, “=”
indicates Ch2. Similar screens may
appear, depending on the number of
cells being charged.
Charge current and charge time.
Supply voltage and input current.
