Door details – Oldcastle BuildingEnvelope HP-1750 User Manual
Page 40
40
JULY 2011
H P - 1 7 5 0
I N S T A L L A T I O N M A N U A L
Web Address: www.oldcastlebe.com
Phone: 1-866-OLDCASTLE (653-2278)
DOOR DETAILS
HP-10481
ACCESS HOLES
LOCATED AT
HORIZONTAL
FASTENERS
HP-10479
ANCHOR JAMB THROUGH
HP-10390 FILLER
LOCATE ANCHORS AT HEAD & SILL
(ADDITIONAL ANCHORS MAY BE
REQUIRED BASED ON PROJECT
CONDITIONS.)
HOLE PLUG REQUIRED
AT VISION AREAS
