The Device Statistics Screen
SEHI User’s Guide 7-23
PORT
This command lets the user view port statistics for ports 1-26 of the
selected module.
Selecting the Appropriate Module/Port
When the Device Statistics screen first appears, statistics are displayed for
Module 1 and Port 1. To view statistics for another module and port, use
the Module x or Port x commands at the bottom of the screen.
To select a module or port:
1. Use the arrow keys to highlight the Module or Port command.
2. Press the SHIFT and + keys, or the SHIFT and - keys until the desired
module or port number appears.
3. Press ENTER. Statistics associated with the selected Module and Port
appear.
Using the ENABLE PORT Command
The ENABLE PORT command lets the user enable the selected port. The
user must first use the PORT command to select the desired port.
Use the following steps to set the ENABLE PORT command:
1. Use the arrow keys to highlight the ENABLE PORT command at the
bottom of the screen.
2. Press ENTER. The corresponding port is enabled and the Port Admin
Status field is updated.
