11.7. VGA Input Connector
Connector: CN101 – 15pin HD-Sub, female
Pin No
Signal
Description
1
Red
Red analog input
2
Green
Green analog input
3
Blue
Blue analog input
4
NC
Not connected (GND)
5
GND (red)
Ground
6
GND (green)
Ground
7
GND (blue)
Ground
8
GND
Ground
9
VGA 5V
+5V DC
10
GND
Ground
11
NC
Not connected
12
SD
Serial Data Line for DDC
13
HSYNC
Horizontal Sync
14
VSYNC
Vertical Sync
15
SCL
Serial clock input for DDC
