OmniView – User’s Guide (V1.)
22 www.kontron.com
9.
Technical Data
OmniView OmniView 156 OmniView 185 OmniView 215
TFT LCD
Display Screen size 15.6" 18.5" 21.5"
Active area 344.2 x 193.5 409.8 x 230 476.6 x 268.1
(H x V) [mm]
Resolution 1366 x 768 1366 x 768 1920 x 1080
(H x V) [pixel] (SVGA) (XGA) (SXGA)
Pixel Pitch
252 x 252 300 x 300 248 x 248
(H x V) [mm]
Colour depth 16.7M 16.7M 16.7 M
Backlight LED LED LED
Brightness cd/m
2
400 350 300
Control signal 1x 6bit LVDS 1x 6bit LVDS 2x 8bit LVDS
Viewing angle (°)
70/70/50/60 70/70/65/60 89/89/89/89
(r / l / u / d)
Contrast ratio
500:1 1000:1 5000:1
Touch Screen Projected Capacitive Projected Capacitive Projected Capacitive
DC IN Power Plug On the bottom side
Power DC: external 24 V power source (limited power source)
AC: via the optional external AC/DC adapter (limited power
source)
VESA 75/100 compliant Rear side
Protection Class IP65 Front (IP20 rear)
9.1. Electrical Specifications
System Type Input voltage Input current
OmniView DC 24 VDC +/- 20% A: max. 1.25 A
OmniViewAC 115-220 VAC +/-20% A: max. 1A
Hint for DC power connection:
The OmniView must be connected only to a LPS (Limited Power Supply) DC mains
power supply complying with the requirements of UL/IEC 60950-1.
Hint for Using the Supplied AC power connection:
Use only a LPS (Limited Power Supply) power supply complying with the
requirements of UL/IEC 60950-1 to connect the OmniView to an AC power source.
