OmniView–User’s Guide (V1)
www.kontron.com 25
11.
Technical Appendix - Interfaces
The following tables contain the plug assignments for the external connections of the OmniView.
Low-active signals are indicated by a minus sign.
11.1. Power Connector – DC Power Supply
The external power supply is connected to the wall power out let by either the optional USA or
EU AC power cable, and uses a standard IEC-60320-C13 power cord (See section 5.1 for details).
WARNING:
Do not attempt to modify or use an AC power cord set that is not the exact type
required. You must use a power cord set that meets the following criteria:

Rating: In the U.S. and Canada, cords must be UL (Underwriters Laboratories, Inc.) Listed/CSA
(Canadian Standards Organization) Certified type SJT, 18-3 AWG (American Wire Gauge). Outside
of the U.S. and Canada, cords must be flexible harmonized () or VDE (Verbena Deutscher
Electrotechniker, German Institute of Electrical Engineers) certified cord with 3x 0.75 mm
conductors rated 250 VAC.

Connector, wall outlet end: Cords must be terminated in grounding-type male plug designed for
use in your region. The connector must have certification marks showing certification by an agency
acceptable in your region and for U.S. must be listed and rated for 125% of the overall current
rating of the server.

Connector, OmniView end: The connector that plugs into the DC power receptacle on the
I/O panel of the OmniView must be an approved power connector approved by Kontron,
America, Molex, power series 5539.

Cord length and flexibility: Cords must be less than 4.5 meters (14.8 feet) long.

See section 5.1 for details of cords approved by Kontron.
