11.2. DVI Input Connector
Connector: CN100 - DVI-D24P
Pin No.
SIGNAL
DESCRIPTION
1
TMDS DATA2-
TMDS DATA2 Differential negative signal
2
TMDS DATA2+
TMDS DATA2 Differential positive signal
3
TMDS DATA2 Shield
Shield for TMDS channel 2
4
NC
Not connected
5
NC
Not connected
6
DDC Clock
Clock DDC Interface
7
DDC Data
Data DDC Interface
8
NC
Not connected
9
TMDS DATA1-
TMDS DATA1 Differential negative signal
10
TMDS DATA1+
TMDS DATA1 Differential positive signal
11
TMDS DATA1 Shield
Shield for TMDS channel 1
12
NC
Not connected
13
NC
Not connected
14
+5V Power
+5V for EDID (un-powered monitor)
15
GND (for +5V)
Ground
16
HPD
Hot Plug Detect
17
TMDS DATA0-
TMDS DATA0 Differential negative signal
18
TMDS DATA0+
TMDS DATA0 Differential positive signal
19
TMDS DATA0 Shield
Shield for TMDS channel 0
20
NC
Not connected
21
NC
Not connected
22
TMDS Clock Shield
Shield for TMDS clock
23
TMDS CLOCK+
TMDS Clock Differential positive signal
24
TMDS CLOCK-
TMDS Clock Differential negative signal
