11.4. DisplayPort Input Connector
Conn: CB102 – W+P: 8470-2-2-1-80-TR
Pin No. Signal Description
1 ML_L3N Main Link Ch. 3 Differential Input negative
2 GND Ground
3 ML_L3P Main Link Ch. 3 Differential Input positive
4 ML_L2N Main Link Ch. 2 Differential Input negative
5 GND Ground
6 ML_L2P Main Link Ch. 2 Differential Input positive
7 ML_L1N Main Link Ch. 1 Differential Input negative
8 GND Ground
9 ML_LN1P Main Link Ch. 1 Differential Input positive
10 ML_LN0N Main Link Ch. 0 Differential Input negative
11 GND Ground
12 ML_LNOP Main Link Ch. 0 Differential Input positive
13 Config1 Config Pin1, connect to GND with 1M
14 Config2 Config Pin2, connect to GND with 1M
15 AUXP Auxiliary Ch. Differential Input positive
16 GND Ground
17 AUXN Auxiliary Ch. Differential Input negative
18 HPD Hot Plug Detect
19 POR Connected to Ground
20 PO Not Connected to internal circuits
