OmniView–User’s Guide (V1)
www.kontron.com 17
6.3.5. Interfaces
6.3.5.1. USB 2.0 Connector
The system is equipped at the bottom side with 1x USB 2.0 type B interface connector. This
connector provides connection from the touch screen to the required CPU/Computer. This cord is
available as an option, and only required if the touch screen function is required.
6.3.5.2. DVI-D Video Connector
The DVI-D supports both digital and analog connections. Digital devices can be connected directly
to this interface of the OmniView. Analog devices should be connected to this interface via a DVI
to VGA adapter (not included).
6.3.5.3. DisplayPort Video Connector
One Display Port (DP) connector comply with Display Port 1.1a specification.
6.3.5.4. VGA input
VGA input is obtained by connecting to a standard 15-pin D-sub female connector via a standard
VGA style cable (not supplied).
