6.4. I/O Panel View

Fig. 8: I/O panel of OmniView

1 USB-B style connector for

touch panel functionality.

2 DC power in connector

3 Display Port input

4 DVI-D female connector

5 VGA input, 15-pin HD-Sub,

female

When powering on the OmniView, make sure that the air intake and exhaust
openings are not obstructed.
