ANALOG GREEN
Analog output carrying the green color signal O
/75R
C3
ANALOG BLUE
Analog output carrying the blue color signal
O
/75R
C4
ANALOG HSYNC
CRT horizontal synchronization output.
O
C5
ANALOG GND
Ground reference for RED, GREEN, and BLUE PWR
C6
ANALOG GND
Ground reference for RED, GREEN, and BLUE PWR
