6.1. OmniView Touch Monitor Base
The touch-monitor base is configurable during ordering as a 15.6”, 18.5” or 21.5” display size.
Each touch-monitor base is equipped with a color TFT-LCD screen and multi-point projected
capacitive touch screen (PCAP). The OmniView is fanless; cooling of the display is through the
surface of the display bezel and air openings located on the top and bottom on the rear of the
display bezel. The tables below detail the technical specifications of the touch-monitor available
options.
When operating the OmniView, make sure the air openings on the rear of the
display bezel are unobstructed.
The OmniView Touch Monitor is designed to comply with IP65 protection class
at the front side.
Table 1. Display Specifications
Specification / Model HMI-OV156-xxxx HMI-OV185-xxxx HMI-OV215-xxxx
Viewable image size (diagonal) 39.6cm (15.6”) 47.01cm (18.51”) 54.6cm (21.5”)
Active Area 344.232mm (H) x 193.536mm (V) 409.8mm (H) x 230.4mm (V) 476.64mm (H) x 268.11mm (V)
Maximum Resolution 1366 x 768 1366 x 768 1920 x 1080
Pixel Pitch 252 x 252 300 x 300 0.248 x 0.248mm
Brightness 300 cd/m
2
(typical) 300 cd/m
2
(typical) 300 cd/m
2
(typical)
Color Depth 16.7 million colors 16.7 million colors 16.7 million colors
Contrast Ratio 500 (typical) 1000 (typical) 5,000:1 (typical)
Response Time 8 ms (typical) 5 ms (typical) 16ms (typical)
Panel Backlight LED LED LED
Table 2. Touch Specifications
Specification / Model HMI-OV156-xxxx HMI-OV185-xxxx HMI-OV215-xxxx
Touch Technology Projected capacitive system Projected capacitive system Projected capacitive system
Sensor stack thickness 1.1mm 1.1mm 1.1mm
Cover glass thickness 1.1 +/-0.2mm 1.1 +/-0.2mm 1.1 +/-0.2mm
Touch Method Fingers and thin gloves Fingers and thin gloves Fingers and thin gloves
Touch Point 6 touches 6 touches 6 touches
Response Time 25ms 25ms 25ms
Interface USB 2.0 USB 2.0 USB 2.0
